Specification:
Item Type: EV Charging Cable
Material: ABS + TPU + Copper + Silver
Certificate: CE, TUV, UKCA
Charging Interface: Type 2 to Type 2, 5m/16.4ft Cable
Charging Head Standard: IEC 62196-2
Protection Grade: IP65
Coupled Insertion Force: >45N, <80N
Impat of Exteral Force: Can Afford 1m Drop and 2t Vehicle Run Over Pressure
Insulation Resistance: >1000MQ (DC500V)
Terminal Temperature Rise: <50K
Contact Resistance: 0.5m Maximum
Contact Bush: Copper Alloy, Silver Plating
Operating Temperature: -30 to 50
Compatibility: Compatible with any Type 2 EV and fully CE, TUV and IEC certified and compliant
Characteristic:
Better Conductivity: Silver plating on the pins ensures greater conductivity, charging efficiency and reduces heat generation.
Ergonomic Design: Angled horizontal bending design, in line with the habit of manual force which allows for convenient plugging and unplugging.
Strong Patience: Highly resistant to the cold and heat, with the cable maintaining flexibility at -30, therefore withstanding colder conditions.
Stronger and Antiaging: The tight, strong molecular structure provides a long lasting charging cable solution, ensuring greater service life.
TPU Cable: Highly resistant to bending, protecting the internal wiring harness to function normally under repeated bending conditions.
Features:
1Compatibility: The charging cable is compatible with 32A public and home charging points. Compatible with Type 2 Electric Vehicles and Type 2 Hybrid Vehicles. Please confirm that your EV or HEV charging interface standard is TYPE 2 / IEC 621962. 2Safety Design: Type 2 to Type 2, 3 phase, maximum output 32A, suitable for , has passed CE, TUV certification. The EV charging cable supports loads up to 7.2KW. The charging head has dustproof cap, which can effectively prevent water from entering. 3Fast Charging: Plug the male end of the power cord into a charging point or other Type 2 output connector, then plug the female end into the car charging port. Capable of charging at 32 amps (7.2kW), it takes full advantage of the maximum output of your home or charging point. 4IP65 Waterproof and 5m Length: With an IP65 water and dust resistance rating, which means the cable will still work even in dirty or rainy situations, the charging cable adds 16.4ft/5m of charging range and can be hung on a wall without taking up space. 5Portable: You don't have to worry about charging when you're outside. Find a suitable public charging station, remove the EV charging cable from the trunk of your EV car, and you're ready to charge your EV.
Package List:
1 x EV Charging Cable
