Specification:
Item Type: Digital Tach Hour Meter
Material: ABS
Power Supply Voltage: 3V
Timing Range: 0-999999H
Timing Accuracy: 1min/0.1H/1H
Maintenance Range: 0-1000H
Speed Range: 0-30000RPM
Speed Accuracy: 10RPM
Display Mode: LCD
Waterproof Rate: IP68
Battery: Built in 1PC button cell battery CR2450 3V 540mah
Function:
- Dual interface display of timing speed.
A. The factory default timing interface, switch the interface by long pressing the button.
- Timing function
A. Record the total working time of the vehicle
B. The timing range is: 0-999999H, which cannot be cleared when totaling.
C. Two sets of single timing can record the time of a certain running of the vehicle. The single timing range is 0-999999H, and the single timing can be reset by pressing the button.
D. Timing method: gasoline induction timing.
- Maintenance reminder
A. According to the maintenance requirements of the engine, set the replacement oil filter, air filter time, and engine maintenance time
B. The maintenance time setting range is 0-1000H, which can be set or closed.
C. Reminder method for replacing oil filter: when the countdown is 0, CHG OIL flashes to remind, long press to reset
D. Change the air filter reminder mode: when the countdown is 0, the CLEAN AIRFILTER flashes to remind, long press to clear
E. Maintenance timing reminder mode: when the countdown is 0, SVC flashes to remind, long press to clear
- Speed function
A. The speed interface displays the current speed of the engine in real time
B. The speed range is: 0-30000RPM
C. 9 kinds of engine strokes can be selected
D. After the engine stops working, the maximum speed of this work will be displayed.
Characteristic:
Indicates operation in RPMs and Hours
Resettable for current JOB time; Total time not resettable
9 programmable firing patterns
Record maximum RPM of engine
Programmable maintenance interval timer(SVC)
Programmable CLEAN AIR FILTER timer Programmable CHG OlL timer
Application: Widely used in hand push lawn mowers, riding lawn mowers, chain saws and other garden machinery; rammers and other road machinery; water motorcycles, outboard motors and other marine industries; vehicle industries such as motorcycles, off road vehicles, ATVs, and snowmobiles; portable generators, RV generators and other generator industries; powered paragliders and other sports equipment; branch chippers, weeders, seeders and other agricultural machinery; and other gasoline engine equipment with spark plugs.
Features:
1Usages: Widely used in garden machinery such as hand push lawn mowers, riding lawn mowers, chain saws, etc.; agricultural machinery such as branch chippers, weeders, seeders, etc. 2Professional Display: The tachometer timer has its own buttons and dual interface display. When the engine is working, you can view the speed, timing, maintenance and other interfaces at will. 3IP68 Protection: The digital tach hour gauge is sealed with epoxy resin, waterproof grade up to IP68, can be used normally in harsh environments such as heavy rain, highly reliable. 4High Compatibility: Applicable to most gasoline engines, 9 kinds of engine strokes can be selected. Built in chip to automatically store data, will not be lost for more than 20 years. 5Inductive Design: Only need to wrap one end of the induction wire around the spark plug 5 times, after the engine ignition signal is continuously detected, the timer will start timing.
Package List:
1 x Digital Tach Hour Meter
2 x Cable Ties
2 x Screw
1 x Manual
1 x Wiring
